Line through the range Φ0.2-Φ2.3mm
Send the spool minimum value 0.01mm
Send a maximum spool 999.99mm
Send the spool maximum speed 108m/mm
Send the spool motor power Japan's sanyo servo motor2.7KW
The camshaft minimum 0.1°
The camshaft maximum 359.9°
The camshaft maximum speed 120RPM
CAM shaft motor power Japan's sanyo servo motor2.7KW
The minimum turning spindle positive and negative direction 0.1°
The revolving axis maximum positive and negative direction 359.9°
It can also be turning spindle motor power Japan's sanyo servo motor1.0KW
The largest production speed 100ppm
The biggest spring diameter Φ50mm
Taiwan CNC computer
The power supply 380V 50Hz
Weight 870kg
